Water & Gas Metering
Mountain States is a preferred vendor for Itron, Diehl, and Honeywell meters.
Honeywell AC-250 NXS Smart
The Honeywell American Meter AC-250NX class meter is part of the AC250NXS Diaphragm Meters Series. It was designed to be one of the industry’s most cost-effective gas meters for residential compact metering, delivering high performance measurement at an economical price.
Being one of the smallest and lightest diaphragm gas meters in the US market, AC-250NXS is reliable, accurate, easy to install and fits in tighter spaces, such as meter trees in apartment complexes. More than 90 million meters based on this measurement cartridge design have been sold worldwide.
The AC-250NXS is available with built-in temperature conversions for accurate measurements. An integrated CAT-M1 cellular communication module enables automatic meter readings to be updated to utilities multiple times in a day to have real time insights of the gas consumption and meter health.
Honeywell American Meter AC-250
The Honeywell American Meter AC-250 is the industry’s most cost-effective gas meter for residential and small commercial applications. It is unequaled for accuracy retention and for life cycle maintenance economies.
The standard for measuring a variety of hydrocarbon gases at pressures up to 10 PSIG and flow rates up to 250 cubic feet per hour.
- Die-cast aluminum case
- Oil-impregnated, self-lubricating bushings
- Molded, convoluted diaphragms for smooth operation and long life
- Rigid, reinforced flag rods for positive alignment and sustained accuracy
- Graphite-filled phenolic valves to minimize wear
- Long-life, low friction, grommet seals
- Single coat polyester primer with high solids polyurethane top coat
- Security seals that indicate tampering
Honeywell evoQ4 Electromagnetic
Water Meter
The Honeywell evoQ4 is a pioneering advance in commercial water metering technology, the evoQ4 delivers unparalleled performance and functionality that meets the typical demands of four commercial meters – compounds, turbines, single jets and mag meters, as well as large positive displacement meters.
Specifications:
- Advanced measurement and flow technology
- 0.5 second sampling rate
- IP68 rated fully submersible
- Lightweight, solid state design
- No moving parts and 10 year battery life eliminate the need for maintenance
- Compatible with industry leading AMR/AMI devices
- Optional bi-directional pulse output – allows utilities to connect to critical water management billing systems making it an ideal revenue meter and powerful distribution management tool
Accurate, versatile and embedded with sophisticated measurement and advanced flow technology, the evoQ4 mag meter delivers high accuracy through a wide range of flows and varied conditions and applications for meter sizes from 1 ½” through 12″.
Given advances in solid state metering and the integration of RF (radio frequency), Itron is pleased to offer the Intelis Gas Meter, an exceptionally compact and feature-rich ultrasonic solid-state residential gas meter with integrated radio frequency communications, temperature sensing, and internal safety shutoff valve.
Diehl Water Meters
- US headquarters and assembly located in Chicago, IL
- More than 150 years in water metering
- Display with alarm codes, including: leakage detection, radio on, and error codes
- IP68 fully potted housing
- 32 configurable events/alarms
Diehl Metering is a global leader in ultrasonic water meter technology and the second largest water meter manufacturer in the world with millions of meters installed annually.
Kamstrup flowIQ® 2200
As the next generation of smart meters, the Kamstrup flowIQ® 2200 raises the bar for what you can expect from a residential water meter. You get uncompromising accuracy, state-of-the-art built-in acoustic leak detection, full support for remote reading and a host of other intelligent features in one superior meter protected from water ingress and with up to 20 years battery life.
- Acoustic leakage detection
- Intelligent alarms
- Battery lifetime up to 20 years
